Part Number # 753-648
SKU # 2323574
Wago 753-648 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 753-648 |
| SKU #: | 2323574 |
| Dimensions: | 3.937 in H x 0.472 in W x 2.717 in D |
| Series: | 753 |
| Terminal Type: | 8 x Cage Clamp |
| Type: | 1 Port |
| UNSPSC: | 32151702 |
| UPC: | 04050821475705 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$766.10 / Each
Quantity:
- WAGO, 753-648, 1 Port, Series: 753, 5 V DC System, 24 V DC Field, 30 mA, 30| mA Bus Current, 8 x Cage Clamp Terminal, 0 to 55 deg C, Polycarbonate/Polyamide 6.6, 3.937 in H x 0.472 in W x 2.717 in D Dimensions
753-648 Application
Used for further applications753-648 Item Features
- 0.078 Mbit Transmission rate
- Twisted pair - FTT Transmission medium
- Copper conductor
- Pluggable connector
- 28 to 14 AWG Solid conductor and Fine-stranded conductor
- 0.35 to 0.39 in Strip length
- LED Indicators
- DIN-35 rail Mounting
- -40 to 85 deg C Storage Ambient Temperature
- 0 to 6562 ft Operating altitude
- 95% Relative humidity (without condensation)
753-648 Standards
RoHS Compliant,With Exemption|ISO/IEC 14908|IP20|IEC 60068-2-6|IEC 60068-2-27|EN 61000-6-2|IEC 60068-2-42|IEC 60068-2-43|IEC 61131-2SKU #2323574Part Number #753-648UNSPSC32151702UPC04050821475705
Image provided may only be a representation of final product and may include optional equipment
