Brand: Wago
WAGO 753-652 RS-232/485 Serial Interface
Image Disclaimers Message
Brand: Wago
WAGO 753-652 RS-232/485 Serial Interface
Brand: Wago
WAGO 753-652 RS-232/485 Serial Interface
Part #:753-652
SKU #: 2366863
$604.78/EA
Key Features
Part #:753-652
SKU #: 2366863
Brand: Wago
Bit transfer: RS-485/-422: ISO 8482 / DIN 66259 - 4; RS-232: EIA/TIA-232-F
Color: Light gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 69 mm / 2.717 inch
$604.78/EA
Specifications
Brand: Wago
Bit transfer: RS-485/-422: ISO 8482 / DIN 66259 - 4; RS-232: EIA/TIA-232-F
Color: Light gray
Connection technology: 8 x CAGE CLAMP®
Country of origin: DE
Depth: 69 mm / 2.717 inch
Height: 100 mm / 3.937 inch
Housing material: Polycarbonate, polyamide 6.6
Isolation: 500 V system/field
Mounting position: Horizontal (standing/lying); vertical
Mounting type: DIN-35 rail
Number of data bits: 7/8, adjustable
Number of stop bits: 1/2, adjustable
Pluggable connector: Yes
Protection type: IP20
Signal type: RS-232 || RS-422 / RS-485
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Vibration resistance: 4g per IEC 60068-2-6
Weight: 42.063 g
Width: 12 mm / 0.472 inch
UNSPSC: 32151603
UPC: 04050821329749
WAGO 753-652 RS-232/485 Serial Interface
Additional Description: WAGO-753-652 RS-232/485 SERIAL INTERFACE; LIGHT GRAY 7530652
Catalog Description: RS-232/485 Serial Interface
