Brand: Wago
WAGO 757-184 M12 sensor/actuator box
Part Number # 757-184
SKU # 2123196
$103.58 / Each
Wago 757-184 Key Features
Brand: Wago
Part Number # 757-184
SKU #2123196
Dimensions: 1.339 in H x 2.362 in W x 5.984 in D
Number of Poles: 4
Connection technology: 1 x M23 plug; 12-pole, 8 x M12 socket; 4-pole; incl. ground
Country of origin: DE
Depth: 152 mm / 5.984 inch
Halogen-free: Yes
Height: 34 mm / 1.339 inch
Housing material: PA 66 (UL 94 V0); RAL 7035; silicon and halogen free
Insulation resistance: 1000 MΩ
Material: Polyamide
Mounting type: Screw, Screw mount
Protection type: IP67
Signal characteristic: PNP
Supply voltage: DC 10 … 30 V; Rated voltage: 32 V ~ rms
Vibration resistance: Per IEC 60068-2-6
Width: 60 mm / 2.362 inch
Manufacturer Name: WAGO Corporation
UNSPSC: 32151702
UPC: 04050821054313
$103.58 / Each
- WAGO, 757-184, Sensor/Actuator Box, 4 Pole, Screw Mounting, Polyamide, 1.339 in H x 2.362 in W x 5.984 in D Dimensions
757-184 Item Features
- M12 sensor/actuator box, 8-way
- 4-pole (1 signal per contact)
- M23 connector (12 in pole)
- Green LED operating indicator
- Yellow LED status indicator
757-184 Standards
RoHS Compliant|IP67SKU #2123196Part Number #757-184UNSPSC32151702UPC04050821054313
