Brand: Wago
757-343
WAGO 757-343 M8 sensor/actuator box
Part Number # 757-343
SKU # 2197933
$84.42 / Each
Wago 757-343 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 757-343 |
| SKU #: | 2197933 |
| Dimensions: | 1.024 in H x 1.181 in W x 4.606 in D |
| Number of Poles: | 3 |
| Connection technology: | 1 x M16 plug; 14-pole, 4 x M8 socket; 3-pole |
| Country of origin: | DE |
| Depth: | 117 mm / 4.606 inch |
| Halogen-free: | Yes |
| Height: | 26 mm / 1.024 inch |
| Housing material: | PA 66 (UL 94 V0); RAL 7035; silicon and halogen free |
| Insulation resistance: | 1000 MΩ |
| Material: | Polyamide |
| Mounting type: | Fastened, Screw, Screw mount |
| Protection type: | IP67 |
| Signal characteristic: | PNP |
| Supply voltage: | DC 10 … 30 V; Rated voltage: 32 V ~ rms |
| Vibration resistance: | Per IEC 60068-2-6 |
| Width: | 30 mm / 1.181 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 32151702 |
| UPC: | 04044918978675 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$84.42 / Each
Quantity:
WAGO 757-343 M8 sensor/actuator box
Brand: Wago
Part Number: 757-343
Additional Description: WAGO-757-343 M8 SENSOR/ACTUATOR BOX; 4-WAY; 3-POLE; M16 CONNECTOR 7570343 WAY/3-P/M16 07570343
Catalog Description: M8 sensor/actuator box; 4-way; 3-pole; M16 connector
757-343 Item Features
- M8 sensor/actuator box, 4-way
- 3-pole (1 signal per contact)
- M16 connector (14 in pole)
- Green LED operating indicator
- Yellow LED status indicator
757-343 Standards
RoHS Compliant|IP67SKU #2197933Part Number #757-343UNSPSC32151702UPC04044918978675
