Part Number # 787-1662/004-1000
SKU # 2352353
Image Disclaimers Message
787-1662/004-1000
WAGO 787-1662/004-1000 787 Circuit Breaker, 24 VDC, 3.8 A, 2 Poles
Part Number # 787-1662/004-1000
SKU # 2352353
$318.34 / Each
Wago 787-1662/004-1000 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 787-1662/004-1000 |
| SKU #: | 2352353 |
| Amperage Rating: | 3.8 A |
| Dimensions: | 3.543 in H x 1.772 in W x 4.547 in D |
| Enclosure Type: | IP20 |
| Number of Poles: | 2 |
| Series: | 787 |
| Temperature Rating (Degrees F): | -25 to 70 deg C |
| Wire Size: | 20 to 8 AWG |
| Connection technology: | Push-in CAGE CLAMP® |
| Connection type: | Push-In |
| Country of origin: | DE |
| Height: | 90 mm / 3.543 inch |
| Mounting type: | DIN Rail, DIN-35 rail |
| MTBF: | > 500,000 h (per IEC 61709) |
| Output voltage range: | DC 20 … 28.8 V (Ue − voltage drop) |
| Protection class: | III |
| Protection type: | IP20 (per EN 60529) |
| Remote input: | Reactivation of all tripped channels via 15 … 30 VDC pulse for min. 500 ms || Switching on/off any number of channels via pulse sequence |
| Reverse voltage protection: | No |
| Signaling: | 2 x LED (green/red/orange) || 1 x Remote control input (S1) || 2 x Active signal output (S2; S3) |
| Solid conductor: | 0.5 … 10 mm² / 20 … 8 AWG |
| Standards/Specifications: | EN 60950; EN 61000-6-2; EN 61000-6-3; UL 508; UL 2367 |
| Switch-on behavior: | Time-delayed channel switching (load-dependent, min. 50 ms / max. 5 s) |
| Total number of channels (module): | 2 |
| Transient suppression (primary): | Suppressor diode (33 V) |
| Voltage drop: | ≤ 125 mV (Input (+)) |
| WAGO Connector: | WAGO 831 Series |
| Weight: | 200.000 g |
| Width: | 45 mm / 1.772 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 43232306 |
| UPC: | 04055143896320 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$318.34 / Each
Quantity:
- WAGO, 787-1662/004-1000, Circuit Breaker, Series: 787, 24 V DC, 3.8 A, 2 Pole, Push-In Connection, 20 to 8 AWG Wire, IP20 Enclosure, DIN Rail Mounting, -25 to 70 deg C, 3.543 in H x 1.772 in W x 4.547 in D Dimensions
787-1662/004-1000 Standards
RoHS Compliant|IEC 61709|IP20|EN 60529|EN 61000-6-2|EN 61000-6-3|UL 508|UL 2367|CESKU #2352353Part Number #787-1662/004-1000UNSPSC43232306UPC04055143896320
