Part Number # 787-870
SKU # 2186810
Image Disclaimers Message
787-870
WAGO 787-870 UPS charger and controller
Part Number # 787-870
SKU # 2186810
Wago 787-870 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 787-870 |
| SKU #: | 2186810 |
| Communication: | RS-232 Serial Interface |
| Connection technology: | CAGE CLAMP® |
| Country of origin: | DE |
| Height: | 163 mm / 6.417 inch |
| Inrush current: | ≤ 4 A (No load) |
| Mounting type: | DIN-35 rail |
| MTBF: | > 500,000 h (per IEC 61709) |
| Output voltage range: | Ui – 1 VDC (rated operation); 20 … 25.5 VDC (buffer mode) |
| Parallel operation: | Yes, max. 3 battery modules for buffer time extension (temperature measurement evaluation is only possible via one battery module) |
| Protection class: | III |
| Protection type: | IP20 (per EN 60529) |
| Remote input: | Switching buffer mode off |
| Reverse voltage protection: | Yes |
| Signaling: | 1 x LED DC OK (green) || 1 x Warning LED (yellow) || 1 x Error LED (red) || LCD || 3 x Signal output (24 VDC; max. 25 mA) || 1 x Isolated relay contact (max. 30 VDC; 1 A) || 1 x RS-232 interface || Battery control (C+; C-) |
| Solid conductor: | 0.08 … 2.5 mm² / 28 … 12 AWG |
| Standards/Specifications: | EN 60950; UL 60950; UL 508; EN 61000-6-2; EN 61000-6-3 |
| WAGO Connector: | WAGO 231 Series |
| Weight: | 800.000 g |
| Width: | 40 mm / 1.575 inch |
| UNSPSC: | 39121004 |
| UPC: | 04045454909857 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
WAGO 787-870 UPS charger and controller
Brand: Wago
Part Number: 787-870
Additional Description: WAGO-787-870 UPS CHARGER AND CONTROLLER; 24 VDC INPUT VOLTAGE; 24 VDC OUTPUT VOLTAGE; 10 A OUTPUT CURRENT; LINEMONITOR; COMMUNICATION CAPABILITY; 2,50 MM 7870870 communicaticapability 250mm INPUT VOLTAGE; 24 VDC OUTPUT VOLTAGE; 10 A OUTPUT CURRENT; LINEMONITOR; COMMUNICATION CAPABILITY; 2,50 MM DISPLAY 07870870
Catalog Description: UPS charger and controller; 24 VDC input voltage; 24 VDC output voltage; 10 A output current; LineMonitor; communication capability; 2,50 mm²
SKU #2186810Part Number #787-870UNSPSC39121004UPC04045454909857
