Name: WAGO 787-875 UPS charger and controller
Brand: Wago
Price: 504.22 US$
Availability: OutOfStock

Brand: Wago

WAGO 787-875 UPS charger and controller

Image Disclaimers Message

Brand: Wago

WAGO 787-875 UPS charger and controller

Brand: Wago

WAGO 787-875 UPS charger and controller

Part #:787-875

SKU #: 2301907

$504.22/EA

Key Features

Part #:787-875

SKU #: 2301907

Brand: Wago

Communication: RS-232 Serial Interface

Connection technology: Push-in CAGE CLAMP®

Country of origin: DE

Height: 171 mm / 6.732 inch

Inrush current: ≤ 4 A (No load)

$504.22/EA

Quantity

Specifications

Brand: Wago

Communication: RS-232 Serial Interface

Connection technology: Push-in CAGE CLAMP®

Country of origin: DE

Height: 171 mm / 6.732 inch

Inrush current: ≤ 4 A (No load)

Mounting type: DIN-35 rail

MTBF: > 500,000 h (per IEC 61709)

Output voltage range: Ui – 1 VDC (rated operation); 20 … 25.5 VDC (buffer mode)

Parallel operation: Yes, max. 3 battery modules for buffer time extension (temperature measurement evaluation is only possible via one battery module)

Protection class: III

Protection type: IP20 (per EN 60529)

Remote input: Switching buffer mode off

Reverse voltage protection: Yes

Signaling: 1 x LED DC OK (green) || 1 x Warning LED (yellow) || 1 x Error LED (red) || LCD || 3 x Signal output (24 VDC; max. 25 mA) || 1 x Isolated relay contact (max. 30 VDC; 1 A) || 1 x RS-232 interface || Battery control (C+; C-)

Solid conductor: 0.5 … 10 mm² / 20 … 8 AWG

Standards/Specifications: EN 60950; UL 60950; UL 508; EN 61000-6-2; EN 61000-6-3

WAGO Connector: WAGO 831 Series

Weight: 1200.000 g

Width: 57 mm / 2.244 inch

UNSPSC: 39121004

UPC: 04045454993917

Description

WAGO 787-875 UPS charger and controller

Additional Description: WAGO-787-875 UPS CHARGER AND CONTROLLER; 24 VDC INPUT VOLTAGE; 24 VDC OUTPUT VOLTAGE; 20 A OUTPUT CURRENT; LINEMONITOR; COMMUNICATION CAPABILITY; 10,00 MM 7870875 communicaticapability 1000mm INPUT VOLTAGE; 24 VDC OUTPUT VOLTAGE; 20 A OUTPUT CURRENT; LINEMONITOR; COMMUNICATION CAPABILITY; 10,00 MM 07870875

Catalog Description: UPS charger and controller; 24 VDC input voltage; 24 VDC output voltage; 20 A output current; LineMonitor; communication capability; 10,00 mm²
