Part Number # 788-103
SKU # 1873414
Image Disclaimers Message
Wago 788-103 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 788-103 |
| SKU #: | 1873414 |
| Color: | Gray |
| Connection technology: | Push-in CAGE CLAMP® |
| Country of origin: | CN |
| Depth: | 86 mm / 3.386 inch |
| Mounting type: | DIN-35 rail |
| Number of changeover/switchover contacts: | 2 |
| Protection type: | IP20 |
| Rated voltage: | 250 V |
| Solid conductor: | 0.34 … 2.5 mm² / 22 … 14 AWG |
| Standards/Specifications: | EN 60664-1 |
| Weight: | 30.980 g |
| Width: | 25 mm / 0.984 inch |
| UNSPSC: | 43232306 |
| UPC: | 04050821591801 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$9.22 / Each
Quantity:
WAGO 788-103 Relay socket
Brand: Wago
Part Number: 788-103
Wago 788-103 788 Series Socket, TS Din 35 Rail Mount, 250 VAC, 16 AMP, Gray, IP 20, -40 To 70 DEG C, Wire Size: 22 - 12 AWG, Cage Clamp Connection, 0.591 Width X 3.39 IN Depth X 2.52 IN Height, Strip Length: 0.37 IN, RoHS Compliant, For 2-Changeover Contacts RS 25 Switching Relay
Additional Description: WAGO-788-103 RELAY SOCKET; 2 CHANGEOVER CONTACTS; FOR 25 MM BASIC RELAYS; GRAY DT DP DT 51269914
Catalog Description: Relay socket; 2 changeover contacts; for 25 mm basic relays; gray
SKU #1873414Part Number #788-103UNSPSC43232306UPC04050821591801
