WAGO 788-150 Basic relay
Part Number # 788-150
SKU # 2280545
$8.53 / Each
Wago 788-150 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 788-150 |
| SKU #: | 2280545 |
| Amperage Rating: | 16 A |
| Dimensions: | 0.5 in W x 1.142 in D |
| Country of origin: | AT |
| Depth: | 29 mm / 1.142 inch |
| Mechanical life: | 30 x 106 switching operations |
| Mounting type: | Pluggable, Pluggable module |
| Number of changeover/switchover contacts: | 1 |
| Standards/Specifications: | EN 61810-1 |
| Switching capacity: | AC-15: 6 A / AC 250 V; DC-13: 2 A / DC 24 V |
| Switching frequency with/without load (max.): | 6 min-1 / 1200 min-1 |
| Weight: | 14.710 g |
| Width: | 12.7 mm / 0.5 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 43232306 |
| UPC: | 04045454303778 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$8.53 / Each
Quantity:
WAGO 788-150 Basic relay
Brand: Wago
Part Number: 788-150
Additional Description: WAGO-788-150 BASIC RELAY; NOMINAL INPUT VOLTAGE: 12 VDC; 1 CHANGEOVER CONTACT; LIMITING CONTINUOUS CURRENT: 16 A; MODULE WIDTH: 13 MM; MODULE HEIGHT: 15 MM 51175659
Catalog Description: Basic relay; Nominal input voltage: 12 VDC; 1 changeover contact; Limiting continuous current: 16 A; Module width: 13 mm; Module height: 15 mm
788-150 Standards
EN 61810-1|RoHS Compliant|IP40SKU #2280545Part Number #788-150UNSPSC43232306UPC04045454303778
