Part Number # 788-180
SKU # 2195932
Image Disclaimers Message
Brand: Wago
788-180
WAGO 788-180 Basic relay
Part Number # 788-180
SKU # 2195932
$18.86 / Each
Wago 788-180 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 788-180 |
| SKU #: | 2195932 |
| Amperage Rating: | 8 A |
| Dimensions: | 0.5 in W x 1.142 in D |
| Country of origin: | AT |
| Depth: | 29 mm / 1.142 inch |
| Mechanical life: | 30 x 106 switching operations |
| Mounting type: | Pluggable, Pluggable module |
| Number of changeover/switchover contacts: | 2 |
| Standards/Specifications: | EN 61810-1 |
| Switching capacity: | AC-15: 3 A / AC 250 V; DC-13: 2 A / DC 24 V |
| Switching frequency with/without load (max.): | 6 min-1 / 1200 min-1 |
| Weight: | 12.900 g |
| Width: | 12.7 mm / 0.5 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 43232306 |
| UPC: | 04050821867920 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$18.86 / Each
Quantity:
WAGO 788-180 Basic relay
Brand: Wago
Part Number: 788-180
Additional Description: WAGO-788-180 BASIC RELAY; NOMINAL INPUT VOLTAGE: 230 VAC; 2 CHANGEOVER CONTACTS; LIMITING CONTINUOUS CURRENT: 8 A; MODULE WIDTH: 13 MM; MODULE HEIGHT: 15 MM 51291888
Catalog Description: Basic relay; Nominal input voltage: 230 VAC; 2 changeover contacts; Limiting continuous current: 8 A; Module width: 13 mm; Module height: 15 mm
788-180 Standards
EN 61810-1|RoHS Compliant|IP40SKU #2195932Part Number #788-180UNSPSC43232306UPC04050821867920
