Part Number # 811-321
SKU # 2235120
Image Disclaimers Message
811-321
WAGO 811-321 2-conductor fuse holder
Part Number # 811-321
SKU # 2235120
$58.09 / Each
Typical price:$62.93 / Each
Wago 811-321 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 811-321 |
| SKU #: | 2235120 |
| Amperage Rating: | 32 A |
| Dimensions: | 4.134 in H x 1.378 in W x 2.165 in D |
| Number of Poles: | 2 |
| Type: | Operating Tool |
| Wire Size: | 14 to 6 AWG |
| Actuation type: | Operating tool |
| Color: | Light gray |
| Connection technology: | CAGE CLAMP® |
| Connection type: | Clamp |
| Depth: | 105 mm / 4.134 inch |
| Insulation material: | Polyamide (PA66) |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail, DIN-35 rail |
| Rated current: | 32 A |
| Solid conductor: | 2.5 … 16 mm² / 14 … 6 AWG |
| Total number of connection points: | 4 |
| Weight: | 11.000 g |
| Width: | 35 mm / 1.378 inch |
| Wiring type: | Side-entry wiring |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04050821508106 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$58.09 / Each
Typical price:$62.93 / Each
Quantity:
- WAGO, 811-321, Operating Tool, 690 V, 32 A, 2 Pole, 14 to 6 AWG Wire, 0.47 to 0.51 in Wire Strip Length, DIN Rail Mounting, Clamp Connection, Polyamide, Light Gray, 4.134 in H x 1.378 in W x 2.165 in D Dimensions
811-321 Standards
CSA 22.2|IEC/HD 60269-2|RoHS CompliantSKU #2235120Part Number #811-321UNSPSC39121410UPC04050821508106
