Part Number # 832-1104/037-9037
SKU # 2418189
832-1104/037-9037
WAGO 832-1104/037-9037 Terminal Blocks
Part Number # 832-1104/037-9037
SKU # 2418189
$184.20 / 10Each
Typical price:$199.50 / Each
Wago 832-1104/037-9037 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 832-1104/037-9037 |
| SKU #: | 2418189 |
| Amperage Rating: | 76 A |
| Dimensions: | 1.146 in H x 2.124 in W x 1.961 in D |
| Number of Poles: | 1 |
| Temperature Rating (Degrees F): | -35 to 60 deg C |
| Type: | Push-In |
| Wire Size: | 18 to 4 AWG |
| Material: | Polybutylene Terephthalate |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04055143921268 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$184.20 / 10Each
Typical price:$199.50 / Each
Quantity:
WAGO 832-1104/037-9037 Terminal Blocks
Brand: Wago
Part Number: 832-1104/037-9037
Additional Description: WAGO-832-1104/037-9037 1-CONDUCTOR FEMALE CONNECTOR, LEVER 60415100
Catalog Description: 1-conductor female connector; lever; Push-in CAGE CLAMP®; 16 mm²; Pin spacing 10.16 mm; 4-pole; 100% protected against mismating; Lateral locking levers; Silver-plated contacts; direct marking; 16,00 mm²; light gray
832-1104/037-9037 Item Features
- Intuitive and tool-free lever actuation
- Universal connection for all conductor types
- Push-in termination of solid or ferruled conductors
- 100 Percent protected against mismating
- Coding option available
832-1104/037-9037 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2418189Part Number #832-1104/037-9037UNSPSC39121410UPC04055143921268
