Part Number # 852-1305
SKU # 2351777
Image Disclaimers Message
852-1305
WAGO 852-1305 Industrial managed switch
Part Number # 852-1305
SKU # 2351777
$1524.92 / Each
Wago 852-1305 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 852-1305 |
| SKU #: | 2351777 |
| Fiber Type: | Multi-Mode/Single-Mode |
| Baud rate: | Copper cable: 10/1000 Mbit/s; Fiber optic:1000 Mbit/s |
| Color: | Metallic black |
| Connection technology: | 1 x Built-in male connector: 231-436/001-000; included female connector (MCS Connectors): 2231-106/026-000, Copper cable: 8 x RJ-45; Fiber optic: 4 x SFP; LC fiber-optic connector |
| Controls: | 14 x DIP switch: Alarm function power supplies and ports 1 … 12; 1 x Reset button: system restart |
| Country of origin: | TW |
| Height: | 162 mm / 6.378 inch |
| Housing material: | Aluminum |
| Mounting type: | DIN-35 rail |
| Number of 1000Base SX/LX ports: | 4 |
| Number of 1000BASE-T ports: | 8 |
| Optical fiber type: | Single-mode and multi-mode |
| Protection type: | IP30 |
| Redundancy function: | Redundant DC power supply; STP; RSTP; MSTP; Jet Ring < 300 ms; Xpress Ring < 20 ms; Dual Homing < 20 ms; Dual Ring; ERPSv2 < 50 ms; LCAP |
| Supply voltage: | DC 12 … 60 V; Cable length:< 3 m |
| Switching mode: | Store‐and‐forward; non-blocking |
| Vibration resistance: | Per IEC 60068-2-6 |
| Weight: | 910.000 g |
| Width: | 50 mm / 1.969 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 32151702 |
| UPC: | 04055143327169 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1524.92 / Each
Quantity:
WAGO 852-1305 Industrial managed switch
Brand: Wago
Part Number: 852-1305
Additional Description: WAGO-852-1305 INDUSTRIAL-MANAGED-SWITCH; 8-PORT 1000BASE-T; 4-SLOT 1000BASE-SX/LX; METALLIC BLACK 60268602
Catalog Description: Industrial Managed Switch; 8 Ports 1000Base-T; 4-Slot 1000BASE-SX/LX; black metallic
852-1305 Application
Ideal for a wide range of applications852-1305 Item Features
- Web-based/SNMP Management
- Redundant DC power supply
- DIP switch to set alarm functions
- Non-blocking, store-and-forward switching, rapid spanning tree protocol (RSTP)
- IGMP snooping for multicast filtering
- Port configuration, status, statistics
- Port trunking
852-1305 Standards
ECCN: 5A992.C|RoHS Compliant|CE|IP30|IEEE 802.3/802.3u/802.3z/802.3x/802.3ad/802.3ab/802.1d/802.1q/802.1p/802.1w/802.1x StandardsSKU #2351777Part Number #852-1305UNSPSC32151702UPC04055143327169
