852-603
WAGO 852-603 Industrial Managed Switch - PROFINET
Part Number # 852-603
SKU # 2391593
$1481.85 / Each
Wago 852-603 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 852-603 |
| SKU #: | 2391593 |
| Interface: | RJ45 |
| Network Type: | 100Base-TX |
| Series: | 852 |
| UNSPSC: | 32151702 |
| UPC: | 04055143908030 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1481.85 / Each
Quantity:
WAGO 852-603 Industrial Managed Switch - PROFINET
Brand: Wago
Part Number: 852-603
WAGO, 852-603, Series: 852, Network: 100Base-TX, RJ45 Interface, 8 Ports
Additional Description: WAGO-852-603 INDUSTRIAL-MANAGED-SWITCH 8PORT 2-SLOT 1000BASE-SX/LX; METALLIC BLACK, 1 PCS. 60411756
Catalog Description: Industrial Managed Switch; 8-port 100Base-TX; 2-Slot 1000BASE-SX/LX; PROFINET; Extended temperature range
852-603 Item Features
- Web-based/SNMP management
- Power supply range - 12 60 VDC
- DIP switches to set alarm functions
- Media redundancy protocol (MRP) as manager (MRM) or client (MRC), redundant ring
- Nonblocking, storeandforward switching, rapid spanning tree protocol (RSTP)
- Autonegotiation and AUTO-MDI/MDIC (crossover)
- IGMP snooping
- Port configuration, status, statistics
- Port trunking and multi-port mirroring
- Time synchronization via SNTP
- Storm control, bandwidth limitation and loop detection
852-603 Standards
RoHS Compliant,No Exemption|IP30|IEC 60068-2-6|IEC 60068-2-27|EN 61000-6-2SKU #2391593Part Number #852-603UNSPSC32151702UPC04055143908030
Image provided may only be a representation of final product and may include optional equipment
