Specifications
Brand: Wago
Amperage Rating: 6 A
Coil Voltage: 250 VAC
Dimensions: 0.59 in H x 0.19 in W x 1.09 in D
Enclosure Type: IP20
Power Rating: 4 kV
Series: 857
Temperature Rating (Degrees F): -40 to 85 deg C
Country of origin: CZ
Depth: 28 mm / 1.09 inch
Mechanical life: 5 x 106 switching operations
Mounting type: Pluggable, Pluggable module
Number of changeover/switchover contacts: 1
Protection type: IP20
Standards/Specifications: EN 61810-1; EN 61373; VDE; UR
Switching capacity: AC-15: 3 A / AC 250 V; DC-13: 2 A / DC 24 V
Switching frequency with/without load (max.): 6 min-1 / 180 min-1
Weight: 4.700 g
Width: 5 mm / 0.197 inch
Manufacturer Name: WAGO Corporation
UNSPSC: 43232306
UPC: 04050821868293
WAGO 857-150 Basic relay
WAGO, 857-150, Relay Module, Series: 857, 6 A, 4 kV Power, 250 VAC Coil, Pluggable Mounting, IP20 Enclosure, -40 to 85 deg C, 0.59 in H x 0.19 in W x 1.09 in D Dimensions
Additional Description: WAGO-857-150 BASIC RELAY; NOMINAL INPUT VOLTAGE: 12 VDC; 1 CHANGEOVER CONTACT; LIMITING CONTINUOUS CURRENT: 6 A; MODULE WIDTH: 5 MM; MODULE HEIGHT: 15 MM 51291919 12 VDC; 1 CHANGEOVER CONTACT; LIMITING CONTINUOUS CURRENT: 6 A; MODULE WIDTH: 5 MM; MODULE HEIGHT: 15 MM 51291919
Catalog Description: Basic relay; Nominal input voltage: 12 VDC; 1 changeover contact; Limiting continuous current: 6 A; Module width: 5 mm; Module height: 15 mm
Item FeaturesRoHS Compliant|EN 61810-1|EN 61373|VDE|UR
