Brand: Wago
857-531
WAGO 857-531 JUMPFLEX signal conditioner
Part Number # 857-531
SKU # 2234026
$339.45 / Each
Wago 857-531 Key Features
Brand: Wago
Part Number # 857-531
SKU #2234026
Color: Light gray
Connection technology: Push-in CAGE CLAMP®
Country of origin: DE
Depth: 94 mm / 3.701 inch
Hysteresis: Adjustable via DIP switch or software
Input signal (current): ±20 mA
Input signal (voltage): ±10 V; 0 … 30 V
Input signal type: Voltage || Current
Mounting type: DIN-35 rail
Number of changeover/switchover contacts: 1
Power consumption at nominal supply voltage: ≤ 25 mA (+ IDO)
Power supply type: 24 VDC
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Standards/Specifications: EN 61373
Supply voltage range: ±30 %
Weight: 38.600 g
Width: 6 mm / 0.236 inch
UNSPSC: 43232306
UPC: 04045454885229
$339.45 / Each
SKU # 2234026
Part Number # 857-531
WAGO 857-531 JUMPFLEX signal conditioner
Brand: Wago
Part Number: 857-531
Additional Description: WAGO-857-531 JUMPFLEX TRANSDUCER; THRESHOLD VALUE SWITCH WITH ANALOG INPUT AND CHANGEOVER RELAY OUTPUT; 2,50 MM; LIGHT GRAY 8570531 swtcwanlgput-changeover relay OP 250mm LtGRA VALUE SWITCH WITH ANALOG INPUT AND CHANGEOVER RELAY OUTPUT; 2,50 MM ; LIGHT GRAY 08570531
Catalog Description: Threshold value switches; Analog values; 1 changeover contact; Digital output; Configuration via software; Supply voltage: 24 VDC; 6 mm module width; 2,50 mm²
