Part Number # 857-560
SKU # 2332201
Brand: Wago
857-560
WAGO 857-560 JUMPFLEX signal conditioner
Part Number # 857-560
SKU # 2332201
$437.55 / Each
Wago 857-560 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 857-560 |
| SKU #: | 2332201 |
| Dimensions: | 3.701 in H x 0.236 in W x 3.85 in D |
| Input Type: | Voltage |
| Input Voltage: | 24 V DC, 24 VDC |
| Temperature Rating (Degrees F): | -40 to 70 deg C |
| Connection technology: | Push-in CAGE CLAMP® |
| Connection type: | Push-In |
| Country of origin: | DE |
| Depth: | 94 mm / 3.701 inch |
| Frequency range: | 10 … 100 Hz (AC) |
| Input signal (voltage): | AC/DC 300 V (IN 1); AC/DC 30 V (IN 2) |
| Input signal type: | Voltage |
| Material: | Polyamide (PA66) |
| Measurement method: | RMS measurement; Arithmetic mean value |
| Mounting type: | 35 mm DIN Rail, DIN-35 rail |
| Output signal (current): | 0 … 10 mA; 2 … 10 mA; 0 … 20 mA; 4 … 20 mA (can be inverted (also bipolar)) |
| Output signal (voltage): | 0 … 5 V; 1 … 5 V; 0 … 10 V; 2 … 10 V |
| Output signal type: | Current || Voltage |
| Output type: | Analog |
| Power consumption at nominal supply voltage: | ≤ 46 mA (+ IDO) |
| Power supply type: | 24 VDC |
| Solid conductor: | 0.08 … 2.5 mm² / 28 … 14 AWG |
| Standards/Specifications: | EN 61010-1; EN 61373 |
| Supply voltage range: | ±30 % |
| Weight: | 39.100 g |
| Width: | 6 mm / 0.236 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 43232306 |
| UPC: | 04055143481571 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$437.55 / Each
Quantity:
WAGO 857-560 JUMPFLEX signal conditioner
Brand: Wago
Part Number: 857-560
Additional Description: WAGO-857-560 VOLTAGE SIGNAL CONDITIONER; VOLTAGE INPUT SIGNAL; CURRENT AND VOLTAGE OUTPUT SIGNAL; DIGITAL OUTPUT; CONFIGURATION VIA SOFTWARE; SUPPLY VOLTAGE: 24 VDC; 6 MM MODULE WIDTH 60306494
Catalog Description: Voltage signal conditioner; Voltage input signal; Current and voltage output signal; Digital output; Configuration via software; Supply voltage: 24 VDC; 6 mm module width
857-560 Item Features
- RMS measurement or arithmetic mean value
- A digital signal output reacts to configured measurement range limits (on/off switching delay and threshold value switch function can be configured with up to two threshold values)
- Switchable filter function
857-560 Standards
EN 61010-1|EN 61373|EN 50121-3-2|EN 50121-3-2|EN 61010-1|EN 61373|RoHS Compliant|CE|IP20SKU #2332201Part Number #857-560UNSPSC43232306UPC04055143481571
Image provided may only be a representation of final product and may include optional equipment
