Part Number # 858-517
SKU # 2367477
Image Disclaimers Message
Brand: Wago
858-517
WAGO 858-517 Relay module
Part Number # 858-517
SKU # 2367477
$164.45 / 5Each
Wago 858-517 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 858-517 |
| SKU #: | 2367477 |
| Amperage Rating: | 5 A |
| Dimensions: | 3.819 in H x 1.22 in W x 2.874 in D |
| Enclosure Type: | IP20 |
| Indicator: | Red LED |
| Temperature Rating (Degrees F): | -25 to 50 deg C |
| Connection technology: | Push-in CAGE CLAMP® |
| Connection type: | Push-In |
| Country of origin: | DE |
| Depth: | 97 mm / 3.819 inch |
| Mechanical life: | 20 x 106 switching operations |
| Mounting type: | 35 mm DIN Rail, DIN-35 rail |
| Number of changeover/switchover contacts: | 4 |
| Protection type: | IP20 |
| Rated voltage: | 250 V |
| Solid conductor: | 0.34 … 1.5 mm² / 22 … 16 AWG |
| Standards/Specifications: | EN 61010-2-201; EN 61810-1; EN 61373; UL 508 (max. 50 °C) |
| Status indicator: | Red LED || Mechanical |
| Switching capacity: | AC-15: 1 A / AC 240 V; DC-13: 2 A / DC 24 V |
| Weight: | 95.300 g |
| Width: | 31 mm / 1.22 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39122323 |
| UPC: | 04055143567855 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$164.45 / 5Each
Quantity:
- WAGO, 858-517, Relay Module, 115 V AC, 5 A, Red LED Indicator, -25 to 50 deg C, Push-In Connection, IP20 Enclosure, 35 mm DIN Rail Mounting, 3.819 in H x 1.22 in W x 2.874 in D Dimensions
858-517 Standards
EN 61010-2-201|EN 61810-1|EN 61373|UL 508 (max. 50°C)|RoHS Compliant|IP20SKU #2367477Part Number #858-517UNSPSC39122323UPC04055143567855
