Brand: Wago
WAGO 859-357 859 Relay Module, 115 VAC, 115 VDC
Image Disclaimers Message
Brand: Wago
WAGO 859-357 859 Relay Module, 115 VAC, 115 VDC
Brand: Wago
WAGO 859-357 859 Relay Module, 115 VAC, 115 VDC
Part #:859-357
SKU #: 973480
$39.65/EA
Key Features
Part #:859-357
SKU #: 973480
Brand: Wago
Dimensions: 3.583 in H x 0.236 in W x 2.205 in D
Enclosure Type: IP20
Indicator: LED
Response Time: 15 ms
Series: 859
$39.65/EA
Specifications
Brand: Wago
Dimensions: 3.583 in H x 0.236 in W x 2.205 in D
Enclosure Type: IP20
Indicator: LED
Response Time: 15 ms
Series: 859
Temperature Rating (Degrees F): -40 to 50 deg C
Voltage Rating: 115 VAC, 115 VDC, 115 VAC/115 VDC
Color: Gray
Connection technology: CAGE CLAMP®
Connection type: Clamp
Country of origin: DE
Depth: 91 mm / 3.583 inch
Mechanical life: 5 x 106 switching operations
Mounting type: 35 mm DIN Rail, DIN-35 rail
Number of changeover/switchover contacts: 1
Rated voltage: 250 V
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Standards/Specifications: EN 61010-2-201; EN 61810-1; EN 61373; GL; UL 508
Status indicator: Red LED
Switching frequency with/without load (max.): 6 min-1 / 180 min-1
Weight: 22.829 g
Width: 6 mm / 0.236 inch
Manufacturer Name: WAGO Corporation
UNSPSC: 43232306
UPC: 04055143604147
Item FeaturesRoHS Compliant
