Brand: Wago
WAGO 859-737 Optocoupler module
Image Disclaimers Message
Brand: Wago
WAGO 859-737 Optocoupler module
Brand: Wago
WAGO 859-737 Optocoupler module
Part #:859-737
SKU #: 2328549
$62.46/EA
Key Features
Part #:859-737
SKU #: 2328549
Brand: Wago
Circuit type: 2-wire connection
Connection technology: CAGE CLAMP®
Country of origin: DE
Depth: 91 mm / 3.583 inch
Mounting type: DIN-35 rail
$62.46/EA
Specifications
Brand: Wago
Circuit type: 2-wire connection
Connection technology: CAGE CLAMP®
Country of origin: DE
Depth: 91 mm / 3.583 inch
Mounting type: DIN-35 rail
Output voltage range: DC 3 … 30 V
Rated voltage: 300 V
Solid conductor: 0.08 … 2.5 mm² / 28 … 14 AWG
Standards/Specifications: EN 61010-2-201; EN 61000-6-2; EN 61000-6-3; EN 61373
Status indicator: Red LED
Switching frequency: ≤ 100 Hz
Turn-off time: ≤ 450 µs
Turn-on time: ≤ 200 µs
Weight: 19.700 g
Width: 6 mm / 0.236 inch
UNSPSC: 43232306
UPC: 04055143605328
WAGO 859-737 Optocoupler module
Additional Description: WAGO-859-737 POWER OPTOCOUPLER 51199265
Catalog Description: Optocoupler module; Nominal input voltage: 24 VDC; Output voltage range: 0 … 30 VDC; Limiting continuous current: 5 A; 2-wire connection; Red status indicator; Module width: 6 mm; gray
