- 2 Clamping Points
- 1 Potentials
- Front-entry wiring
Specifications
Brand: Wago
Amperage Rating: 24 A
Dimensions: 1.75 in H x 0.19 in W x 1.08 in D
Number of Poles: 1
Power Rating: 6 kV
Series: 870
Temperature Rating (Degrees F): -60 to 105 deg C
Terminal Type: Through
Type: 2-Conductor
Voltage Rating: 500 V
Wire Size: 28 to 14 AWG
Actuation type: Operating tool
Color: Blue
Connection technology: CAGE CLAMP®
Connection type: Cage Clamp
Country of origin: DE
Depth: 44.5 mm / 1.752 inch
Insulation material: Polyamide (PA66)
Material: Polyamide (PA66)
Mounting type: 35 mm DIN Rail, DIN-35 rail
Rated current: 24 A
Solid conductor: 0.08 … 2.5 mm² / 28 … 12 AWG
Total number of connection points: 2
Weight: 4.313 g
Width: 5 mm / 0.197 inch
Wiring type: Front-entry wiring
Manufacturer Name: WAGO Corporation
UNSPSC: 39121410
UPC: 04044918478380
Item FeaturesSuitable for Ex i applications
Item Features
Item FeaturesRoHS Compliant
