Brand: Wago
890-205
WAGO 890-205 Wire Connectors
Part Number # 890-205
SKU # 2353757
$5.18 / Each
Typical price:$5.61 / Each
Wago 890-205 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 890-205 |
| SKU #: | 2353757 |
| Dimensions: | 0.461 in H x 0.929 in W x 1.343 in D |
| Type: | Operating Tool |
| Wire Size: | 22 to 16 AWG |
| Actuation type: | Operating tool || Push-in |
| Application: | General mains applications |
| Coding: | A |
| Color: | Black |
| Conductor entry direction to mating direction: | 0 ° |
| Connection technology: | Push-in CAGE CLAMP® |
| Connector (connection type): | For conductor |
| Contact material: | Copper or copper alloy (surface-treated) |
| Country of origin: | PL |
| Depth: | 34.1 mm / 1.343 inch |
| Height: | 11.7 mm / 0.461 inch |
| Insulation material: | Polyamide (PA66) |
| Marking: | N ⏚ 1 2 3 |
| Material: | Polyamide (PA66) |
| Nominal cross-section: | 1.5 mm² |
| Potential marking: | N ⏚ 1 2 3 |
| Protection type: | IP20 |
| Rated current: | 13 A |
| Solid conductor: | 0.25 … 1.5 mm² / 22 … 16 AWG |
| Stranded conductor: | 0.25 … 1 mm² / 22 … 18 AWG |
| Total number of connection points: | 5 |
| Weight: | 6.070 g |
| Width: | 23.6 mm / 0.929 inch |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121409 |
| UPC: | 04055143548571 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$5.18 / Each
Typical price:$5.61 / Each
Quantity:
- WAGO, 890-205, Socket, Operating Tool, 400 V, 22 to 16 AWG Wire, 0.173 in Pitch/Row Spacing, Polyamide (PA66), Black, 0.461 in H x 0.929 in W x 1.343 in D Dimensions
890-205 Application
For General mains applications890-205 Item Features
- Effective protection against mismating
- Compact design for conductors with a cross-section up to 1.5 mm^2
- Custom-engineered solutions
- Fast, secure installation
890-205 Standards
IEC/EN 60664-1|RoHS CompliantSKU #2353757Part Number #890-205UNSPSC39121409UPC04055143548571
