Part Number # 2201-1404
SKU # 2443444
2201-1404
Wago 2201-1404
Part Number # 2201-1404
SKU # 2443444
Wago 2201-1404 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2201-1404 |
| SKU #: | 2443444 |
| Amperage Rating: | 18 A |
| Dimensions: | 2.752 in H x 0.165 in W x 1.555 in D |
| Number of Poles: | 1 |
| Type: | Operating Tool |
| Wire Size: | 22 to 14 AWG |
| Connection type: | Clamp |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04055143696876 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Wago 2201-1404
Brand: Wago
Part Number: 2201-1404
Additional Description: WAGO-2201-1404 4-CONDUCTOR THROUGH TERMINAL BLOCK; WITH PUSH-BUTTON; 1.5 MM ; WITH TEST PORT; SUITABLE FOR EX I APPLICATIONS; SIDE AND CENTER MARKING; FOR DIN-RAIL 35 X 15 AND 35 X 7.5; PUSH-IN CAGE CLAMP ; 1,50 MM ; BLUE
Catalog Description: 4-conductor through terminal block; with push-button; 1.5 mm²; with test port; suitable for Ex i applications; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP®; 1,00 mm²; blue
2201-1404 Application
Suitable for Ex i applications2201-1404 Standards
CSA 22.2 No 158|ATEX: PTB 18 ATEX 1004 U / IECEx: PTB 18.0011U (Ex eb IIC Gb)|RoHS CompliantSKU #2443444Part Number #2201-1404UNSPSC39121410UPC04055143696876
Image provided may only be a representation of final product and may include optional equipment
