Part Number # 2206-1304
SKU # 2442665
2206-1304
Wago 2206-1304
Part Number # 2206-1304
SKU # 2442665
Wago 2206-1304 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2206-1304 |
| SKU #: | 2442665 |
| Amperage Rating: | 41 A |
| Dimensions: | 2.886 in H x 0.295 in W x 1.555 in D |
| Number of Poles: | 1 |
| Type: | Operating Tool |
| Wire Size: | 20 to 8 AWG |
| Connection type: | Clamp |
| Material: | Polyamide |
| Mounting type: | 35 mm DIN Rail, DIN Rail |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121410 |
| UPC: | 04055143712101 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
Wago 2206-1304
Brand: Wago
Part Number: 2206-1304
Additional Description: WAGO-2206-1304 3-CONDUCTOR THROUGH TERMINAL BLOCK; WITH PUSH-BUTTON; 6 MM; WITH TEST PORT; SUITABLE FOR EX I APPLICATIONS; SIDE AND CENTER MARKING; FOR DIN-RAIL 35 X 15 AND 35 X 7.5; PUSH-IN CAGE CLAMP; 6,00 MM; BLUE 60361284
Catalog Description: 3-conductor through terminal block; with push-button; 6 mm²; with test port; suitable for Ex i applications; side and center marking; for DIN-rail 35 x 15 and 35 x 7.5; Push-in CAGE CLAMP®; 6,00 mm²; blue
2206-1304 Application
Suitable for Ex i applications2206-1304 Standards
CSA 22.2 No 158|ATEX: PTB 18 ATEX 1007 U / IECEx: PTB 18.0014U|RoHS CompliantSKU #2442665Part Number #2206-1304UNSPSC39121410UPC04055143712101
Image provided may only be a representation of final product and may include optional equipment
