Part Number # 2231-303/026-000
SKU # 2459408
2231-303/026-000
Wago 2231-303/026-000
Part Number # 2231-303/026-000
SKU # 2459408
$4.53 / Each
Typical price:$4.91 / Each
Wago 2231-303/026-000 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2231-303/026-000 |
| SKU #: | 2459408 |
| Amperage Rating: | 16 A |
| Dimensions: | 0.591 in H x 0.659 in W x 1.008 in D |
| Number of Poles: | 3 |
| Temperature Rating (Degrees F): | -35 to 60 deg C |
| Type: | Push Button |
| Wire Size: | 24 to 12 AWG |
| Connection type: | Push-In |
| Material: | Polyamide |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121421 |
| UPC: | 04045454696481 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$4.53 / Each
Typical price:$4.91 / Each
Quantity:
- WAGO, 2231-303/026-000, 1-Conductor Female Connector, Push Button, 630 V, 16 A, 3 Pole, 24 to 12 AWG Wire, 0.39 to 0.43 in Wire Strip Length, Push-In Connection, -35 to 60 deg C, Polyamide, Orange, 0.591 in H x 0.659 in W x 1.008 in D Dimensions
2231-303/026-000 Item Features
- Universal connection for all conductor types
- Easy-to-use design does not require specialty tools
- Ability to wire while mated
- Push-in termination of solid and ferruled conductors
- Integrated test ports for testing parallel to the conductor entry
- Coding option available
2231-303/026-000 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2459408Part Number #2231-303/026-000UNSPSC39121421UPC04045454696481
