Wago 2604-1101 Key Features
| Brand: | Wago |
|---|---|
| Part Number # : | 2604-1101 |
| SKU #: | 2448340 |
| Amperage Rating: | 32 A |
| Dimensions: | 0.815 in H x 0.291 in W x 0.756 in D |
| Number of Poles: | 1 |
| Spacing: | 0.197 in |
| Type: | Lever |
| Wire Size: | 24 to 12 AWG |
| Connection type: | Push-In |
| Material: | Polyamide |
| Manufacturer Name: | WAGO Corporation |
| UNSPSC: | 39121421 |
| UPC: | 04055143564281 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$1.07 / Each
Typical price:$1.16 / Each
Quantity:
Wago 2604-1101
Brand: Wago
Part Number: 2604-1101
Additional Description: WAGO-2604-1101 PCB TERMINAL BLOCK; LEVER; 4 MM ; PIN SPACING 5 MM; 1-POLE; PUSH-IN CAGE CLAMP ; 4,00 MM ; GRAY 60325990
Catalog Description: PCB terminal block; lever; 4 mm²; Pin spacing 5 mm; 1-pole; Push-in CAGE CLAMP®; 4,00 mm²; gray
2604-1101 Item Features
- Push-in termination of solid and ferruled conductors
- Intuitive and tool-free operation
- Several clamping units can be held open simultaneously, simplifying the connection of multi-core cables
- Testing can be performed both parallel and perpendicular to conductor entry
2604-1101 Standards
CSA|IEC/EN 60664-1|RoHS CompliantSKU #2448340Part Number #2604-1101UNSPSC39121421UPC04055143564281
