Weidmuller 1000120001 Printed Circuit Board Pcb Press Fit Header Connector
Part Number # 1000120001
SKU # 2324420
1000120001
Weidmuller 1000120001 Printed Circuit Board Pcb Press Fit Header Connector
Part Number # 1000120001
SKU # 2324420
$244.50 / 30Each
Typical price:$281.34 / Each
Weidmuller 1000120001 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1000120001 |
| SKU #: | 2324420 |
| Connector Type: | Female Plug |
| Dimensions: | 20.7 mm H x 55.88 mm W x 26.2 mm D |
| Number of Positions: | 11 |
| Series: | BL/SL 5.08 |
| Temperature Rating (Degrees F): | -50 to 100 deg C |
| Termination Type: | Push-In/Tension Clamp |
| Type: | High Current Wire Connection |
| Wire Size: | 26 to 12 AWG |
| Contact material: | CuSn |
| Country of origin: | RO |
| Housing material: | PBT |
| Insulation resistance: | >=10^8 Ohm |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 31163101 |
| UPC: | 04032248690060 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$244.50 / 30Each
Typical price:$281.34 / Each
Quantity:
- Weidmuller OMNIMATE Signal PCB Plug-In Connector, High Current Wire Connection, Series: BL/SL 5.08, 11 Positions, 1 Rows, 5.08 mm Pitch/Row Spacing, 26 to 12 AWG Wire, 300/400 V, Female Plug Connector, Push-In/Tension Clamp Termination, CuSn Contact, >=10^8 Ohm Insulation Resistance, PBT Housing Material, -50 to 100 deg C, Black, 20.7 mm H x 55.88 mm W x 26.2 mm D Dimensions
1000120001 Item Features
- 3 tested-and-proven wire outlet directions provide the usual flexibility for application specific design
- 4 flange variations and the patented release latch allow the locking concept to be based on the requirements of the user
- Use the BLF 5.08HC and SL 5.08HC plug combination to reach the maximum rated specifications
- 400 V IEC, 300 V UL
1000120001 Standards
RoHS Compliant|IEC 60664-1, 61984|CSA No. 200039-1121690|UL 1059|cULus No. E60693 Recognized|UL 94 V-0 Flammability Rating|EAC CertifiedSKU #2324420Part Number #1000120001UNSPSC31163101UPC04032248690060
Image provided may only be a representation of final product and may include optional equipment
