Weidmuller 1036400000 Terminal Block

2151477 MFG #: 1036400000
$599.00 / EA
Usually Ships within 5-8 Days

Weidmuller 1036400000 Terminal Block

Weidmueller 1036400000 Feed Through Terminal, W-Series Single Tier, 4 Terminal, Wire Size: 30 - 12 AWG Rated, 26 - 12 AWG Factory Wiring UL, 22 - 12 AWG Field Wiring UL, 22 - 12 AWG CSA, M2.5 Terminal, 24 AMP Rated, 20 AMP UL, 20 AMP CSA, 21 AMP ATEX, Voltage Rating: 400 V Rated, 300 V UL, 300 V CSA, 275 V ATEX, Material: V-0 UL 94 Flammable Wemid, Beige, Mounting: Snap-On, Screw On Side Connection, 69-1/2 MM Length X 5.1 MM Width X 62-1/2 MM Height, 2 Clamping Points Per Level, 6 KV Rated Impul

Additional Description: WEID-1036400000 (T) WDK 2.5 DU-PE

Catalog Description: Weidmueller 1036400000 Feed Through Terminal, W-Series Single Tier, 4 Terminal, Wire Size: 30 - 12 AWG Rated, 26 - 12 AWG Factory Wiring UL, 22 - 12 AWG Field Wiring UL, 22 - 12 AWG CSA, M2.5 Terminal, 24 AMP Rated, 20 AMP UL, 20 AMP CSA, 21 AMP ATEX, Voltage Rating: 400 V Rated, 300 V UL, 300 V CSA, 275 V ATEX, Material: V-0 UL 94 Flammable Wemid, Beige, Mounting: Snap-On, Screw On Side Connection, 69-1/2 MM Length X 5.1 MM Width X 62-1/2 MM Height, 2 Clamping Points Per Level, 6 KV Rated Impulse Withstand Voltage, -50 To 120 DEG C Continuous Operating Temperature, 4 SQ-MM Wire Connection Cross Section, UL E60693VOL1SEC38 Listed, CSA 200039-1057876 Certified, IEC 60947-7-1 (-7-2) Certified, ATEX KEMA98ATEX1687U Certified, CE Certified, CURUSEX, PCT ME25, EX Certified, ROHS Compliant
