Brand: Weidmuller
Weidmuller 1061000000 Terminal Block
Part Number # 1061000000
SKU # 2250872
Brand: Weidmuller
1061000000
Weidmuller 1061000000 Terminal Block
Part Number # 1061000000
SKU # 2250872
$257.50 / 25Each
Typical price:$296.40 / Each
Weidmuller 1061000000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1061000000 |
| SKU #: | 2250872 |
| Dimensions: | 1.772 in H x 0.481 in D |
| Series: | BV/SV 7.62HP |
| Temperature Rating (Degrees F): | -50 to 125 deg C |
| UNSPSC: | 39121410 |
| UPC: | 04032248810741 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$257.50 / 25Each
Typical price:$296.40 / Each
Quantity:
Weidmuller 1061000000 Terminal Block
Brand: Weidmuller
Part Number: 1061000000
Additional Description: WEID-1061000000 SVF 7.62HP/05/180SF SN BK BX PCB PLUG-IN CONNECTOR (WIRE CONNECTION), 7.62 MM, NUMBER OF POLES: 5, PUSH IN WITHOUT ACTUATOR, TENSION-CLAMP CONNECTION
Catalog Description: Pluggable PCB connection with innovative connection technology for safe and intuitive handling.
1061000000 Application
For enclosures with a maximum wall thickness of 2 mm1061000000 Item Features
- 180 deg inverted pin header with push-in connection technology for field wiring in 6 sq-mm in a 7.62 pitch, as a three flange variant for enclosure feed-through
- Also perfect as a touch safe solution for reverse voltages
1061000000 Standards
RoHS Compliant|IEC 60664-1|IEC 61984|IEC 61800-5-1|UL 1059|CSA File No. 200039-1121690|cULus File No. E60693|EAC Certified|UL 94 V-0 Flammability RatingSKU #2250872Part Number #1061000000UNSPSC39121410UPC04032248810741
Image provided may only be a representation of final product and may include optional equipment
