Weidmuller 1081430000 Bulkhead Pass Through Connector
Part Number # 1081430000
SKU # 2409327
1081430000
Weidmuller 1081430000 Bulkhead Pass Through Connector
Part Number # 1081430000
SKU # 2409327
$80.41 / Each
Typical price:$92.57 / Each
Weidmuller 1081430000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1081430000 |
| SKU #: | 2409327 |
| Dimensions: | 111.5 mm H x 80 mm W x 216 mm D |
| Entry Type: | PG36 |
| Specifications: | SZ 8, 60 mm H x 187 mm W Mounting, IP68/IP69K Degree of Protection |
| Suitable For Use With: | ModuPlug Modular System and RockStar Heavy Duty Connector |
| Temperature Rating (Degrees F): | -50 to 125 deg C |
| Type: | EMC Industry Plug-In Standard |
| UNSPSC: | 32151901 |
| UPC: | 04032248877478 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$80.41 / Each
Typical price:$92.57 / Each
Quantity:
- Weidmuller Closed Connector Base, EMC Industry Plug-In Standard, Side Entry Position, PG36 Entry, Panel Mounting, For Use With: ModuPlug Modular System and RockStar Heavy Duty Connector, -50 to 125 deg C, Specifications: SZ 8, 60 mm H x 187 mm W Mounting, IP68/IP69K Degree of Protection, Die Cast Aluminum, Black, Powder Coated, 111.5 mm H x 80 mm W x 216 mm D Dimensions
1081430000 Application
Transport and Traffic Engineering, Energy Technology and Extreme Protection Class Requirement Applications1081430000 Item Features
- Clamping yoke connection
- The new RockStar enclosures are resistant to seawater and offer a high degree of shock resistance, meet IP68 and IP69K and have been developed for use under extreme environmental conditions and designed for the high vibration requirements according to DIN EN 61373 cat. 2 (bogie)
- As such, this housing family is ideally suited for fault and maintenance-free operation of heavy duty connectors in transport and traffic engineering as well as in power engineering and in applications with extreme requirements
- During development, measures were also implemented to make the enclosures extremely EMC-resistant
1081430000 Standards
RoHS Compliant|CE CertifiedSKU #2409327Part Number #1081430000UNSPSC32151901UPC04032248877478
Image provided may only be a representation of final product and may include optional equipment
