1218390000
Weidmuller 1218390000 General Purpose Relay
Part Number # 1218390000
SKU # 2401629
$528.60 / 10Each
Weidmuller 1218390000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1218390000 |
| SKU #: | 2401629 |
| Dimensions: | 98.1 mm H x 16 mm W x 63.8 mm D |
| UNSPSC: | 39122325 |
| UPC: | 04050118002409 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$528.60 / 10Each
Quantity:
Weidmuller 1218390000 General Purpose Relay
Brand: Weidmuller
Part Number: 1218390000
Additional Description: WEID-1218390000 RCIKITZ 24VDC 2CO LD/FG RELAY MODULE, 24 V DC ±10 %, GREEN LED, FREE-WHEELING DIODE, 2 CO CONTACTS FORCIBILY GUIDED (EN 61810-3 TYPE B) (AGCUNI) , 250 V AC, 6 A, TENSION-CLAMP CONNECTION, TEST BUTTON AVAILABLE: NO
Catalog Description: Assembly of plug-in relay and plug-in socket. Control circuit and load circuit are electrically isolated.
1218390000 Item Features
- Coupling relay with positively driven contacts for monitoring signals within safety critical circuits
- Relays with positively driven contacts have a 99% diagnostics coverage and an excellent reputation for use in safety systems
- The contacts interlock with each other in order to ensure a synchronous switching status between both contacts
- This guarantees that the alert contact will maintain the same switching status in the event of an error (for example, if the working contact melts from an overload)
- Relay socket for rail mounting
- Retaining clip
- Pluggable relay modules
- Markers
1218390000 Standards
RoHS Compliant|REACH SVHC Lead 7439-92-1 Compliant|DIN EN 50205|cULus File No. E223759 Recognized|UL 94 V-1 Flammability Rating|CE CertifiedSKU #2401629Part Number #1218390000UNSPSC39122325UPC04050118002409
Image provided may only be a representation of final product and may include optional equipment
