1435590000
Weidmuller 1435590000 Signal Conditioners
Part Number # 1435590000
SKU # 2402458
$231.37 / Each
Weidmuller 1435590000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1435590000 |
| SKU #: | 2402458 |
| Dimensions: | 112.5 mm H x 6.1 mm W x 114.3 mm D |
| Response Time: | <=30/<300 ms |
| Specifications: | 2 Pollution Severity, 2-Way Isolator, 14 to 20 AWG Wire, PT100 / 2-/3-/4-Wire Sensor |
| Temperature Rating (Degrees F): | -25 to 70 deg C |
| Connection type: | Screw |
| Country of origin: | DK |
| Mounting type: | TS35 Rail |
| Output current: | 4 to 20 mA |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 39121020 |
| UPC: | 04050118240641 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$231.37 / Each
Quantity:
- Weidmuller Temperature Transducer, 4 to 20 mA Output Current, 0.48 W Power, Screw Connection, TS35 Rail Mounting, -25 to 70 deg C, <=30/<300 ms Response, <+/-0.05 % Accuracy, Specifications: 2 Pollution Severity, 2-Way Isolator, 14 to 20 AWG Wire, PT100 / 2-/3-/4-Wire Sensor, 112.5 mm H x 6.1 mm W x 114.3 mm D Dimensions
1435590000 Item Features
- Safe and space saving (6 mm) isolation and conversion
- Quick installation of the power supply unit using the CH20M mounting rail bus
- Easy configuration via DIP switch or FDT/DTM software
- High interference resistance
1435590000 Standards
RoHS Compliant|UL/cULus File No. E337701|ATEX File No. KEMA10ATEX0183X|IECEX File No. IECEXKEM10.0090X|IEC 61326-1|NE 21|FM Approved|EAC Certified|DNV-GL ApprovedSKU #2402458Part Number #1435590000UNSPSC39121020UPC04050118240641
Image provided may only be a representation of final product and may include optional equipment
