Weidmuller 1479680000 Relay Module
Weidmuller 1479680000 Relay Module
Part #:1479680000
SKU #: 2325807
$123.10/10EA
Key Features
Part #:1479680000
SKU #: 2325807
Brand: Weidmuller
Amperage Rating: 16 A
Coil Voltage: 24 VDC
Contact Form: 1CO
Dimensions: 89.6 mm H x 12.8 mm W x 87.8 mm D
Enclosure Type: IP20
$123.10/10EA
- Space saving, just 6.4 mm modular width
- AgNi contact
- Slim design with 6.4 mm or 12.8 mm W
- Distinctive fiber optic illuminated status display
- 5 cross connection levels
- Clear marking
- Pluggable relays and SSRs
- Wide range of accessories
Specifications
Brand: Weidmuller
Amperage Rating: 16 A
Coil Voltage: 24 VDC
Contact Form: 1CO
Dimensions: 89.6 mm H x 12.8 mm W x 87.8 mm D
Enclosure Type: IP20
Power Rating: 530 mW
Series: TERMSERIES
Temperature Rating (Degrees F): -40 to 60 deg C
Terminal Type: Screw
UNSPSC: 39122325
UPC: 04050118288032
Weidmuller 1479680000 Relay Module
Additional Description: WEID-1479680000 TRS 24VDC 1CO 16A RELAY MODULE, 24 V DC ±20 %, GREEN LED, FREE-WHEELING DIODE, REVERSE POLARITY PROTECTION, 1 CO CONTACT (AGNI) , 250 V AC, 16 A, SCREW CONNECTION, TEST BUTTON AVAILABLE: NO
Catalog Description: Assembly of plug-in relay and plug-in socket. Control circuit and load circuit are electrically isolated.
