1580860000
Weidmuller 1580860000 Quick Disconnects
Part Number # 1580860000
SKU # 2424665
$48.98 / 100Each
Typical price:$56.40 / Each
Weidmuller 1580860000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1580860000 |
| SKU #: | 2424665 |
| Connector Type: | Male Header |
| Dimensions: | 11.6 mm H x 12 mm W x 12 mm D |
| Number of Positions: | 2 |
| Series: | BL/SL 5.00 Series |
| Temperature Rating (Degrees F): | -50 to 100 deg C |
| Termination Type: | THT Solder |
| Type: | Board Connection |
| Contact material: | CuSn |
| Country of origin: | DE |
| Housing material: | PBT |
| Mounting type: | PCB |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 31163101 |
| UPC: | 00040081900544 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$48.98 / 100Each
Typical price:$56.40 / Each
Quantity:
- Weidmuller OMNIMATE Signal PCB Plug-In Connector, Board Connection, Series: BL/SL 5.00 Series, 2 Positions, 1 Row, 5 mm Pitch/Row Spacing, PCB Mounting, 300/400 V, Male Header Connector, THT Solder Termination, CuSn Contact, PBT Housing Material, -50 to 100 deg C, Orange, 11.6 mm H x 12 mm W x 12 mm D Dimensions
1580860000 Item Features
- Male connectors with 90 deg outlet direction
- The solder pin length is optimized for wave flow soldering
- The pin headers provide space for labeling and can be coded
- 400 V IEC, 300 V UL
1580860000 Standards
RoHS Compliant|IEC 60664-1, 61984|CSA No. 200039-1121690|UL 1059|UL No. E60693 Recognized|EAC Certified|UL 94 V-0 Flammability RatingSKU #2424665Part Number #1580860000UNSPSC31163101UPC00040081900544
