1665810000
Weidmuller 1665810000 Electrical Plug
Part Number # 1665810000
SKU # 2244334
$27.59 / Each
Typical price:$31.77 / Each
Weidmuller 1665810000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1665810000 |
| SKU #: | 2244334 |
| Dimensions: | 75 mm H x 71.5 mm W x 82 mm D |
| Entry Type: | PG29 |
| Finish: | Powder Coated |
| Specifications: | IP65 Degree of Protection, Side-Locking Clamp on Lower Side, 1.2 N-m Tightening Torque, SZ 7 |
| Suitable For Use With: | RockStar NEMA Type 4X Plug Housing and HDC Enclosure |
| Temperature Rating (Degrees F): | -40 to 125 deg C |
| Type: | Standard |
| Country of origin: | CN |
| Material: | Die Cast Aluminum |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 32151901 |
| UPC: | 04008190422837 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$27.59 / Each
Typical price:$31.77 / Each
Quantity:
- Weidmuller Hood, Standard, Top Entry Position, PG29 Entry, For Use With: RockStar NEMA Type 4X Plug Housing and HDC Enclosure, -40 to 125 deg C, Specifications: IP65 Degree of Protection, Side-Locking Clamp on Lower Side, 1.2 N-m Tightening Torque, SZ 7, Die Cast Aluminum, Gray, Powder Coated, 75 mm H x 71.5 mm W x 82 mm D Dimensions
1665810000 Application
Industrial Applications1665810000 Item Features
- Special die cast alloy and the multi-layered surface sealing provide complete protection for the HDC housings
- Cleverly designed interlock system is manufactured from stainless steel
- Guarantees a long lifespan with high resistance to corrosion and impact
- Housing interlock system provides integrated safety
- Unique, patented spring system provides the housing interlock with a secure grip and prevents accidental opening
- Laser marking allows for easy and quick identification
- Each housing is permanently labelled with a laser marking so that each product can be quickly designated and positioned
1665810000 Standards
RoHS Compliant|CE Certified|cULus Recognized|REACH SVHC Lead 7439-92-1SKU #2244334Part Number #1665810000UNSPSC32151901UPC04008190422837
Image provided may only be a representation of final product and may include optional equipment
