Weidmuller 1769090000 Printed Circuit Board Pcb Press Fit Header Connector
Part Number # 1769090000
SKU # 2247149
1769090000
Weidmuller 1769090000 Printed Circuit Board Pcb Press Fit Header Connector
Part Number # 1769090000
SKU # 2247149
$119.68 / 64Each
Typical price:$137.47 / Each
Weidmuller 1769090000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1769090000 |
| SKU #: | 2247149 |
| Dimensions: | 28.7 mm H x 23.86 mm W x 21.6 mm D |
| UNSPSC: | 39121443 |
| UPC: | 04032248115921 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$119.68 / 64Each
Typical price:$137.47 / Each
Quantity:
Weidmuller 1769090000 Printed Circuit Board Pcb Press Fit Header Connector
Brand: Weidmuller
Part Number: 1769090000
Additional Description: WEID-1769090000 LM2N 5.08/06/90 3.5SN BK BX PCB TERMINAL, 5.08 MM, NUMBER OF POLES: 6, CONDUCTOR OUTLET DIRECTION: 90 , CLAMPING YOKE CONNECTION
Catalog Description: PCB terminal block (print terminal, board terminal) for simple and safe data transmission directly to the PCB.
1769090000 Item Features
- Single and multi-row PCB terminal with proven clamping yoke connection at 5.08 mm pitch
- Suitable for conductor cross-sections up to 2.5 sq-mm
- 630 V IEC, 300 V UL
- 17.5 A IEC, 15 A UL
1769090000 Standards
RoHS Compliant|CSA 200039-1815154|cULus File No. E60693 Recognized|EAC Certified|UL 94 V-0 Flammability Rating|UL 1059SKU #2247149Part Number #1769090000UNSPSC39121443UPC04032248115921
Image provided may only be a representation of final product and may include optional equipment
