Part Number # 1790030000
SKU # 2337349
1790030000
Weidmuller 1790030000 Contact Insert
Part Number # 1790030000
SKU # 2337349
$99.59 / Each
Typical price:$112.04 / Each
Weidmuller 1790030000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1790030000 |
| SKU #: | 2337349 |
| Dimensions: | 47.8 mm H x 34 mm W x 111 mm D |
| Finish: | Silver Passivated |
| Number of Positions: | 12+Ground |
| Series: | MixMate Series |
| Specifications: | SZ 8, 690 V, 100 A |
| Suitable For Use With: | RockStar Heavy Duty Connector |
| Temperature Rating (Degrees F): | -40 to 125 deg C |
| Wire Size: | 6 to 2 AWG |
| Connection type: | Axial Screw/Male |
| Country of origin: | DE |
| Material: | PC Glass Fiber Reinforced |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 32151901 |
| UPC: | 04032248212095 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$99.59 / Each
Typical price:$112.04 / Each
Quantity:
Weidmuller 1790030000 Contact Insert
Brand: Weidmuller
Part Number: 1790030000
Additional Description: WEID-1790030000 HDC S6 6 SAS CONTACT INSERT (INDUSTRY PLUG-IN CONNECTORS), PIN, 690 V, 100 A, NUMBER OF POLES: 12, AXIAL SCREW CONNECTION, SIZE: 8
Catalog Description: Insert for industrial plug-in connectors, consisting of contact element and insulating body.
1790030000 Item Features
- The MixMate series of connectors can simultaneously transmit high rated currents and voltages as well as signals
- An axial screw can be used to secure the wire
1790030000 Standards
RoHS Compliant|CSA Certified|UL 94V-0 Flammable Rating|DIN EN 61984|cULus Recognized|EAC Certified|UL File No. E92202SKU #2337349Part Number #1790030000UNSPSC32151901UPC04032248212095
Image provided may only be a representation of final product and may include optional equipment
