1833380000
Weidmuller 1833380000 Terminal Blocks
Part Number # 1833380000
SKU # 2425122
$107.66 / 50Each
Typical price:$119.60 / Each
Weidmuller 1833380000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1833380000 |
| SKU #: | 2425122 |
| Amperage Rating: | 57 A |
| Dimensions: | 60 mm H x 9.9 mm W x 46.5 mm D |
| Series: | W Series |
| Temperature Rating (Degrees F): | -60 to 130 deg C |
| Terminal Size: | M4 |
| Torque Rating: | 1.2 to 1.9 N-m |
| Type: | Feed-Through Standard |
| Wire Size: | 10 sq-mm |
| Connection type: | Screw |
| Country of origin: | DE |
| Material: | Wemid |
| Mounting type: | Snap-Fit |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 39121410 |
| UPC: | 04050118044904 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$107.66 / 50Each
Typical price:$119.60 / Each
Quantity:
- Klippon Terminal Block, Feed-Through Standard, Series: W Series, 1 kV, 57 A, 10 sq-mm Wire, 12 mm Wire Strip Length, M4 Terminal, 1.2 to 1.9 N-m Torque, Snap-Fit Mounting, Screw Connection, -60 to 130 deg C, Wemid, White, 60 mm H x 9.9 mm W x 46.5 mm D Dimensions
1833380000 Item Features
- Klippon connect with clamping yoke technology
- The high reliability and variety of designs of the terminal blocks with clamping yoke connections make planning easer and optimizes operational safety
- Klippon connect provides a proven response to a range of different requirements
1833380000 Standards
RoHS Compliant|ATEX File No. DEMKO14ATEX1338U|IECEX File No. IECEXULD14.0005U|EN 60079-7 Ex eb II C Gb|Ex 2014/34/EU Label: II 2 G D|CSA File No. 200039-1057876|EAC Certified|UL File No. E60693|IEC 60664-1|IEC 61984|UL 94 V-2 Flammability RatingSKU #2425122Part Number #1833380000UNSPSC39121410UPC04050118044904
