Brand: Weidmuller
Weidmuller 1892130001 Electrical Receptacle
Part Number # 1892130001
SKU # 2236637
Brand: Weidmuller
1892130001
Weidmuller 1892130001 Electrical Receptacle
Part Number # 1892130001
SKU # 2236637
$27.01 / Each
Typical price:$28.50 / Each
Weidmuller 1892130001 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1892130001 |
| SKU #: | 2236637 |
| Dimensions: | 15.2 mm H x 40.28 mm W x 20.1 mm D |
| UNSPSC: | 32151902 |
| UPC: | 04032248733330 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$27.01 / Each
Typical price:$28.50 / Each
Quantity:
- Weidmuller OMNIMATE Signal PCB Plug-In Connector, Wire Connection, Series: BL/SL 5.08 Series, 6 Positions, 1 Row, 5.08 mm Pitch/Row Spacing, 26 to 12 AWG Wire, 300/400 V, Female Plug Connector, 0.75 sq-mm Connector, Clamping Yoke Termination, Copper Alloy Contact, >=10^8 Ohm Insulation Resistance, PBT Housing Material, -50 to 100 deg C, Orange, 15.2 mm H x 40.28 mm W x 20.1 mm D Dimensions
1892130001 Item Features
- Female plugs with clamping yoke screw connection for wire, with straight wire outlet and release lever mechanism
- The female plugs provide space for labelling and can be coded
- 400 V IEC, 300V UL
- https://youtu.be/Ifq_mdNjF4g
1892130001 Standards
RoHS Compliant|UL File No. E60693 Recognized|IEC 60664-1, IEC 61984|CSA Certified|UL 94 V-0 Flammability Rating|CSA File No. 200039-1121690|EAC CertifiedSKU #2236637Part Number #1892130001UNSPSC32151902UPC04032248733330
Image provided may only be a representation of final product and may include optional equipment
