1930210000
Weidmuller 1930210000 Terminal Blocks
Part Number # 1930210000
SKU # 2363224
$559.00 / 50Each
Typical price:$643.65 / Each
Weidmuller 1930210000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 1930210000 |
| SKU #: | 2363224 |
| Connector Size: | 6 sq-mm |
| Temperature Rating (Degrees F): | -50 to 125 deg C |
| UNSPSC: | 39121410 |
| UPC: | 04032248580088 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$559.00 / 50Each
Typical price:$643.65 / Each
Quantity:
- Weidmuller OMNIMATE Power PCB Plug-In Connector, High Performance Wire Connection, 7 Positions, 1 Row, 7.62 mm Pitch/Row Spacing, 24 to 8 AWG Wire, 600/1000 V, Female Plug Connector, 6 sq-mm Connector, Clamping Yoke Termination, Copper Alloy Contact, >=10^8 Ohm Insulation Resistance, PA GF Housing Material, -50 to 125 deg C, Black
1930210000 Application
Labelling Applications1930210000 Item Features
- High performance female header with the proven, 100% maintenance-free Weidmuller steel clamping yoke
- Side by side mounting without sacrificing any poles or with patented multifunction flange for secure, fast fixing without tools
- Maximum connection and operating reliability thanks to a mating profile that prevents incorrect connection, with unique coding diversity, protection against faulty wiring and 4-point contact
- 1000 V IEC, 600 V UL
- https://youtu.be/9zHojbSnX-8
1930210000 Standards
RoHS Compliant|cULus File No. E60693 Recognized|IEC 60664-1, IEC 61984|CSA Certified|UL 94 V-0 Flammability Rating|CSA File No. 200039-1534443|EAC CertifiedSKU #2363224Part Number #1930210000UNSPSC39121410UPC04032248580088
Image provided may only be a representation of final product and may include optional equipment
