2562740000
Weidmuller 2562740000 Terminal Blocks
Part Number # 2562740000
SKU # 2428585
$873.53 / 50Each
Typical price:$970.30 / Each
Weidmuller 2562740000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 2562740000 |
| SKU #: | 2428585 |
| Amperage Rating: | 6.3 A |
| Dimensions: | 2.362 in H x 0.311 in W x 2.815 in D |
| Number of Poles: | 2 |
| Series: | W Series |
| Temperature Rating (Degrees F): | -60 to 130 deg C |
| Terminal Size: | 0.8 x 4.0 mm |
| Terminal Type: | Blade |
| Torque Rating: | 0.8 to 1.6 N-m |
| Type: | Standard |
| Wire Size: | 20 to 8 AWG |
| Connection type: | Clamping Yoke Screw |
| Country of origin: | CZ |
| Material: | Wemid |
| Mounting type: | Snap-Fit |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 39121410 |
| UPC: | 04050118571516 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$873.53 / 50Each
Typical price:$970.30 / Each
Quantity:
- Weidmuller, 2562740000, Terminal Blocks, Standard, Series: W Series, 36 V, 6.3 A, 2 Pole, 20 to 8 AWG Wire, 12 mm Wire Strip Length, Blade Terminal, 0.8 x 4.0 mm Terminal, 0.8 to 1.6 N-m Torque, Snap-Fit Mounting, Clamping Yoke Screw Connection, -60 to 130 deg C, Wemid, Dark Beige, 2.362 in H x 0.311 in W x 2.815 in D Dimensions
2562740000 Item Features
- In some applications it is useful to protect the feed through connection with a separate fuse
- Fuse terminal blocks are made up of one terminal block bottom section with a fuse insertion carrier
- The fuses vary from pivoting fuse levers and pluggable fuse holders to screwable closures and flat plug-in fuses
2562740000 Standards
RoHS Compliant|CCC-Ex Certified|DEMKOATEX|IECEXULD|UKEX|UR ListedSKU #2428585Part Number #2562740000UNSPSC39121410UPC04050118571516
Image provided may only be a representation of final product and may include optional equipment
