Brand: Weidmuller
7760054115
Weidmuller 7760054115 Signal Distributor
Part Number # 7760054115
SKU # 2286019
$239.79 / Each
Weidmuller 7760054115 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 7760054115 |
| SKU #: | 2286019 |
| Dimensions: | 117.2 mm H x 12.5 mm W x 113.7 mm D |
| Input Type: | Analog |
| Input Voltage: | >17 VDC |
| Response Time: | </=0.5 ms |
| Series: | ACT20P |
| Specifications: | 20 to 30 VDC Supply, 2 kV Insulation, -40 to 85 deg C Storage, 5 to 95% Non-Condensation Humidity |
| Temperature Rating (Degrees F): | -20 to 60 deg C |
| Connection type: | Screw |
| Country of origin: | CN |
| Input current: | 0 to 20/4 to 20 mA |
| Output current: | 0 to 20/4 to 20 mA |
| Output type: | HART Digital Signal |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 39121020 |
| UPC: | 06944169656569 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$239.79 / Each
Quantity:
Weidmuller 7760054115 Signal Distributor
Brand: Weidmuller
Part Number: 7760054115
Additional Description: WEID-7760054115 ACT20P-CI-2CO-S SIGNAL CONVERTER/INSULATOR, SIGNAL DISTRIBUTOR, HART , INPUT : 0(4)-20 MA, OUTPUT : 2 X 0(4) - 20 MA
Catalog Description: Isolating amplifier for recording electrical and physical parameters. With electrical isolation, universally applicable.
7760054115 Item Features
- Precise and highly functional signal converters
- Release levers simplify handling
- HART compatible for 0.5 to 2.5 kHz
- The active or passive mA signal inputs are fully galvanically isolated
- Operating status display on a front panel LED
- Galvanic 4-way isolation between input, output and supply
7760054115 Standards
RoHS Compliant|REACH SVHC Lead 7439-92-1|CE Certified|cULus Listed for hazardous Locations C1D2|cULusEX Listed|ATEX Certified|EAC Certified|IEC EX CertifiedSKU #2286019Part Number #7760054115UNSPSC39121020UPC06944169656569
