Part Number # 8924670000
SKU # 2277058
Image Disclaimers Message
Brand: Weidmuller
8924670000
Weidmuller 8924670000 Terminal Block
Part Number # 8924670000
SKU # 2277058
$148.15 / Each
Typical price:$160.82 / Each
Weidmuller 8924670000 Key Features
| Brand: | Weidmuller |
|---|---|
| Part Number # : | 8924670000 |
| SKU #: | 2277058 |
| Dimensions: | 90 mm H x 17.8 mm W x 69 mm D |
| Electrical Ratings: | 5 VAC/VDC, 450 mA |
| Enclosure Type: | IP20 |
| Environmental Conditions: | -40 to 70 deg C Operating, -40 to 85 deg C Storage, 5 to 96% Relative Humidity |
| Number of Poles: | 1 |
| Series: | VSPC Series |
| Terminal Type: | Plug |
| Type: | 2-Signal |
| Color: | Orange |
| Country of origin: | PL |
| Manufacturer Name: | Weidmuller |
| UNSPSC: | 39121634 |
| UPC: | 04032248696314 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$148.15 / Each
Typical price:$160.82 / Each
Quantity:
- Weidmuller Surge Voltage Arrester, 2-Signal, Series: VSPC Series, 5 VAC/VDC, 450 mA Electrical Rating, 1 Pole, 2.5 kA Nominal Discharge, Environmental Conditions: -40 to 70 deg C Operating, -40 to 85 deg C Storage, 5 to 96% Relative Humidity, IP20 Enclosure, Plug Terminal, Orange, 90 mm H x 17.8 mm W x 69 mm D Dimensions
8924670000 Application
For data interface, instrumentation and control8924670000 Item Features
- Data surge protection for RS422 and RS485 signals
- Can also be connected as T-branch with K21 wall mounted housing
- 2.5 kA 8/20 us wire-wire/wire-PE/GND-PE nominal discharge current
- 5 VAC/VDC, 450 mA IEC/EN
- Without warning function and function indicator
8924670000 Standards
RoHS Compliant|UL 497b File No. E311081|REACH SVHC Lead 7439-92-1|GOST Certificate|CE Certified|CSA Certified|CSAEX Certified|EAC Certified|Functional Safety Certified|OVE Certified|cUL Listed|IEC 61643-21 C2|IEC 61643-21 C3|IEC 61643-21 D1|UL 94 V-0 Flammability RatingSKU #2277058Part Number #8924670000UNSPSC39121634UPC04032248696314
