Part Number # 19251-100
SKU # 2304997
Image Disclaimers Message
Brand: FLIR COMMERCIAL SYSTEMS, INC.
19251-100
FLIR COMMERCIAL SYSTEMS, INC. 19251-100
Part Number # 19251-100
SKU # 2304997
$383.59 / Each
FLIR COMMERCIAL SYSTEMS, INC. 19251-100 Key Features
Brand: | FLIR COMMERCIAL SYSTEMS, INC. |
---|---|
Part Number # : | 19251-100 |
SKU #: | 2304997 |
Series: | IRW |
Material: | Anodized Aluminum |
UNSPSC: | 31242002 |
UPC: | 00084518800282 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$383.59 / Each
Quantity:
FLIR COMMERCIAL SYSTEMS, INC. 19251-100
Brand: FLIR COMMERCIAL SYSTEMS, INC.
Part Number: 19251-100
Additional Description: FLIR-IRW-3C IR WINDOW 3" 19251-100
19251-100 Specifications
- Minimizes time and cost of complying with NFPA 70e requirements for electrical inspections
- Mount on steel and LEXAN® panels
- No screw holes to drill or screws to attach
- Window labeling/id number inside the cover
- 500 deg F maximum operating temperature
- 4.22 in H x 3.89 in W x 1.05 in THK
- 1665 kg maximum pullout strength
- 2474 deg F maximum temperature
- 739 bb Greenlee punch
- Gasket material is silicone
- Hardware material is steel
- Decreases risk of arc flash incidents and resultant injuries (compared with other inspection methods)
- Optic material is calcium fluoride
- Perform both visual and thermal inspections through the broadband crystal window which is compatible with all thermal cameras and UV, visual and fusion inspections (fusion requires a camera with led light feature)
- Integrity and environmental ratings of cabinets are intact even after installation
- Rugged anodized aluminum frame and cover
- Hinged cover always stays attached to base unit (minimizes risk of dropping parts around electrical cabinets)
- Windows are sized to match dimensions of standard knockout punches
- Easy to install - 3 step installation
- Provides approximately 30x more holding surface area securing the window to the cabinet door (vs. Mounting screws)
SKU #2304997Part Number #19251-100UNSPSC31242002UPC00084518800282
