Part Number # THQC2115GFT
SKU # 2446352
ABB THQC2115GFT Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | THQC2115GFT |
| SKU #: | 2446352 |
| UNSPSC: | 39121601 |
| UPC: | 00783164485646 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ABB THQC2115GFT
Brand: ABB
Part Number: THQC2115GFT
Additional Description: ABB -THQC2115GFT THQC 2P 120/240V 15A GFCI SELF-TEST
Catalog Description: Q line circuit breakers are one-inch wide per pole, compact, thermal-magnetic devices designed for residential and commercial applications. The QL breakers are plug-in versions of the Q Line used for connection to load centers and lighting panels. All Q Line circuit breakers feature Quick-make / Quick-break mechanisms, common trip bars, and easy to spot trip indication to ensure safety and reliability. Q Line breakers are available in 1, 2, and 3 pole versions, can be ordered with auxiliary contact and shunt trip accessories, and can be ordered for use in HID applications. 5GFT Amps 15 A
THQC2115GFT Application
Model 3 Ground Fault Circuit Interrupter (GFCI), Residential, Commercial and Outdoor ApplicationsTHQC2115GFT Item Features
- Copper stabs, tin plated for corrosion resistance, make the connection reliable and permanent
- Heat resistant thermoset cases and covers add stability and structural rigidity
- Trips are easy to spot because handles trip to the center position
- The dedicated calibration screw is cemented (not simply papered over) to prevent shifting, the result is stable calibration for optimum trip performance
- Class A (5 mA ground fault trip level)
- 14 to 8 AWG Cu, 12 to 8 AWG Al wire range
- 30 mA, 1 and 2-pole ground fault with self-test feature interrupter
- 10 kA at 120/240 VAC interrupt rating
THQC2115GFT Standards
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL E11592/E51075|HACR RatedSKU #2446352Part Number #THQC2115GFTUNSPSC39121601UPC00783164485646
Image provided may only be a representation of final product and may include optional equipment
