Part Number # TXQB1120
SKU # 2448116
Image Disclaimers Message
Brand: ABB
TXQB1120
ABB TXQB1120
Part Number # TXQB1120
SKU # 2448116
$257.87 / Each
ABB TXQB1120 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | TXQB1120 |
| SKU #: | 2448116 |
| Actuator Type: | Pivot Handle |
| Amperage Rating: | 20 A |
| Dimensions: | 1 in W x 2-3/8 in D x 3-9/32 in H |
| Frame: | THQB/Q-Line |
| Frequency Rating: | 50 to 60 Hz |
| Interrupt Rating: | 65 kA |
| Number of Poles: | 1 |
| Phase: | 1 |
| Temperature Rating (Degrees F): | 10 to 50 deg C |
| Trip Type: | Fixed Thermal Magnetic/LI/Non-Interchangeable, Thermal Magnetic |
| Type: | Type TXQB |
| Wire Size: | 14 to 8 AWG, 12 to 8 AWG |
| Connection type: | Load Lug |
| Material: | Plastic |
| Mounting type: | Bolted-On |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121601 |
| UPC: | 00783164024647 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
$257.87 / Each
Quantity:
- GE Q-Line Miniature Circuit Breaker, Type TXQB, 120/240 V AC, 20 A, 50 to 60 Hz, 65 kA Interrupt, THQB/Q-Line Frame, Thermal Magnetic Trip, 1 Pole, 1 ph, Pivot Handle Actuator, Load Lug, 14 to 8 AWG, 12 to 8 AWG Wire, Bolted-On Mount, 10 to 50 deg C, 1 in W x 2-3/8 in D x 3-9/32 in H, Plastic
TXQB1120 Application
Industrial, Switchboards, Motor Control Centers, Lighting, Power, Customized Control Panelboards, Electrical Distribution and Control ApplicationsTXQB1120 Item Features
- Copper stabs, tin plated for corrosion resistance, make the connection reliable and permanent
- Heat resistant thermoset cases and covers add stability and structural rigidity
- Trips are easy to spot because handles trip to the center position
- The dedicated calibration screw is cemented (not simply papered over) to prevent shifting, the result is stable calibration for optimum trip performance
- 14 to 8 AWG Cu, 12 to 8 AWG Al wire range
- 65 kA at 120 VAC, 65 kA at 120/240 VAC interrupt rating
TXQB1120 Standards
E11592SKU #2448116Part Number #TXQB1120UNSPSC39121601UPC00783164024647
