Part Number # 9T58K0072
SKU # 2454445
9T58K0072
ABB 9T58K0072
Part Number # 9T58K0072
SKU # 2454445
ABB 9T58K0072 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | 9T58K0072 |
| SKU #: | 2454445 |
| Dimensions: | 6.81 in W x 5.81 in H |
| Type: | Fully Encapsulated Harmonic Mitigation |
| Circuit type: | 14225 Frame |
| UNSPSC: | 39121026 |
| UPC: | 00783173153840 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ABB 9T58K0072
Brand: ABB
Part Number: 9T58K0072
GE Power Control Transformer, Fully Encapsulated Harmonic Mitigation, Series: 9T58K, 230/460/575 V AC Primary, 115/95 VAC Secondary, 1 kVA, 50 Hz, 1 ph, Pressure Plate, 14225 Frame, Panel Mount, IS-12, NEMA 1, 40 deg C, Plastic Housing, 6.81 in W x 5.81 in H
Additional Description: ABB -9T58K0072 1C,1KVA,575230-115/95,100C,C&C,TB,I P IP
Catalog Description: ABB's Machine tool core and coil transformers are isolation transformers designed to provide a high degree of secondary voltage stability (regulation) during a brief period of overload condition (also referred to as “inrush current”). They are ideal for applications where power regulation and space optimization are critical. Machine tool core and coil transformers feature welded cores to deliver outstanding performance, long life, and quiet operation.
9T58K0072 Application
Electrical Distribution, Machine Tool, Industrial Control, Panelboard and General Purpose Applications9T58K0072 Item Features
- Core and coil transformers for machine tool applications are used to provide voltage to control devices in applications where regulation and minimum space are important
- Fully encapsulated coil is impervious to moisture
- Terminal board is anchored in the epoxy for greater reliability
- Wide variety of fusing options
- Rugged, high impact plastic terminal board
- Full head #8 brass screws assure quick, easy terminations with maximum connection integrity
- Flexible design allows input or output voltage to match any application
- Copper windings
- Pressure plate terminals ensure secure connections
- 100 deg C temperature rise
- K1-factor rated transformer
- 180 deg C insulation temperature, terminal board type
- Type IP and open core and coil power control transformer
- Transformers are built to standard sound level
- 14225 frame
- IS-12 insulation system
9T58K0072 Standards
CE Marking|cUL Listed|GSA Compliant|UL 506 File No. E2739SKU #2454445Part Number #9T58K0072UNSPSC39121026UPC00783173153840
Image provided may only be a representation of final product and may include optional equipment
