Part Number # 9T58K1815
SKU # 2409633
Image Disclaimers Message
9T58K1815
ABB 9T58K1815 Core And Coil Transformer
Part Number # 9T58K1815
SKU # 2409633
ABB 9T58K1815 Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | 9T58K1815 |
| SKU #: | 2409633 |
| Dimensions: | 5.8 in H x 6.8 in W x 8.8 in D |
| Enclosure Type: | NEMA 3R |
| Frequency Rating: | 60 Hz |
| Insulation: | IS-12 |
| Phase: | 1 |
| Primary Voltage: | 240x480 VAC |
| Secondary Voltage: | 120/240 VAC |
| Series: | 9T |
| Temperature Rating (Degrees F): | 100 deg C |
| Type: | Type QB Dry Encapsulated Open |
| Connection type: | Lead/Pressure Plate |
| Mounting type: | Panel |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121026 |
| UPC: | 00783173151426 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ABB 9T58K1815 Core And Coil Transformer
Brand: ABB
Part Number: 9T58K1815
Additional Description: ABB -9T58K1815 (N) 1C,3KVA,240X480-120/240,100C,CLO,IP NON-CANCELABLE, NON-RETURNABLE
Catalog Description: ABB's General purpose encapsulated open core, and coil transformer (also known as Type IP Control Power transformers) are ideally suited for industrial and light-duty loads, HVAC applications, signal and alarm systems, industrial control panels, lighting, and circuit isolation. The optional fuse block adapter kits enable input and output flexibility. Type IP Control Power transformers are an economical alternative to high in-rush/machine tool transformers.
9T58K1815 Application
General Purpose, Industrial Control, Machine Tool, Panelboard, Electrical Distribution and Control Applications9T58K1815 Item Features
- Core and coil transformers for machine tool applications are used to provide voltage to control devices in applications where regulation and minimum space are important
- Fully encapsulated coil is impervious to moisture
- Pressure plate terminals ensure secure connections
- Terminal board is anchored in the epoxy for greater reliability
- Rugged, high impact plastic terminal board
- Full head #8 brass screws assure quick, easy terminations with maximum connection integrity
- Copper windings
- Flexible design allows input or output voltage to match any application
9T58K1815 Standards
ARRA Compliant|Buy American Act Compliant|RoHS Compliant|UL Listed|cUL Listed|CE Certified|UL 5085, File No. E2739|CSA C22.2 No. 66, File No. 3272SKU #2409633Part Number #9T58K1815UNSPSC39121026UPC00783173151426
