Part Number # T6PA800DW-4SPEC
SKU # 2396093
T6PA800DW-4SPEC
ABB T6PA800DW-4SPEC Molded Case Circuit Breaker
Part Number # T6PA800DW-4SPEC
SKU # 2396093
ABB T6PA800DW-4SPEC Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | T6PA800DW-4SPEC |
| SKU #: | 2396093 |
| Amperage Rating: | 800 A |
| Dimensions: | 10.55 in H x 8.26 in W x 4.07 in D |
| Frame: | T6 |
| Frequency Rating: | 50/60 Hz |
| Number of Poles: | 4 |
| Series: | Tmax |
| Trip Type: | Molded Case Switch |
| Connection type: | Fixed Front Flat |
| Country of origin: | IT |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121616 |
| UPC: | 08057558648132 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ABB T6PA800DW-4SPEC Molded Case Circuit Breaker
Brand: ABB
Part Number: T6PA800DW-4SPEC
ABB Molded Case Circuit Breaker, Series, 600, Amperage Rating VAC/VDC, A 800, Frequency Rating, Hz 50/60, Frame, Molded Case Switch Trip, Trip Range, 4 Pole, Phase, Connection Type, Wire Size, Enclosure Type, Temperature Rating, 10.55 in H x 8.26 in W x 4.07 in D, Material, Finish
Additional Description: ABB -T6PA800DW-4SPEC (N) T6N-D/PV 800 MCS UL 4P F F 1000V DC NON-CANCELABLE, NON-RETURNABLE
Catalog Description: TMAX Molded Case Switch frame size T6, 800A, 4 pole, permanent supply, fixed and front flat terminals, Underwriters Laboratory (sold in the US)
T6PA800DW-4SPEC Application
For power distribution and reverse feed applicationsT6PA800DW-4SPEC Item Features
- Double insulation, this construction characteristic allows for the UL listed field installation of internal accessories without exposure to energized parts
- Positive operation, breakers from ABB ensure that the toggle indicates the precise position of the moving contacts, this guarantees safe and reliable signaling by the device
- Installation, Tmax molded case circuit breakers can be installed in panels and switchboards in either the horizontal or vertical planes while being fed from either end without any derating of their performance characteristics
- Compact size
- The T6 breaker is an 800 A frame with either a microprocessor based over current protective trip system
T6PA800DW-4SPEC Standards
CSA Certified|IEC 60947-2|UL 489SKU #2396093Part Number #T6PA800DW-4SPECUNSPSC39121616UPC08057558648132
Image provided may only be a representation of final product and may include optional equipment
