Part Number # T8VBD3GC0EACEEDT
SKU # 2293637
Image provided may only be a representation of
final product and may include optional equipment
T8VBD3GC0EACEEDT
ABB T8VBD3GC0EACEEDT Molded Case Circuit Breaker
Part Number # T8VBD3GC0EACEEDT
SKU # 2293637
ABB T8VBD3GC0EACEEDT Key Features
| Brand: | ABB |
|---|---|
| Part Number # : | T8VBD3GC0EACEEDT |
| SKU #: | 2293637 |
| Amperage Rating: | 2000, 2000 A |
| Dimensions: | 15 in H x 16.8 in W x 11.2 in D |
| Frame: | 2000, 2000 A |
| Frequency Rating: | 50/60, 50/60 Hz |
| Interrupt Rating: | 100, 100 kA |
| Number of Poles: | 3 |
| Series: | Tmax |
| Trip Type: | Electronic, PR331/P T8 LSI, PR331/P-T8-LSI |
| Type: | Very High Interrupt |
| Country of origin: | IT |
| Manufacturer Name: | ABB |
| UNSPSC: | 39121616 |
| UPC: | 08057558255422 |
Buy Now Pay Later
Get 30 days to pay with Net 30 Terms. Apply Now.
ABB T8VBD3GC0EACEEDT Molded Case Circuit Breaker
Brand: ABB
Part Number: T8VBD3GC0EACEEDT
ABB Molded Case Circuit Breaker, Very High Interrupt, Series, 600, Amperage Rating VAC, A 2000, Frequency Rating, Hz 50/60, 100 Interrupt, Frame kA, A 2000, PR331/P-T8-LSI Trip, Trip Range, 3 Pole, Phase, Connection Type, Wire Size, Enclosure Type, Temperature Rating, 15 in H x 16.8 in W x 11.2 in D, Material, Finish
Additional Description: ABB -T8VBD3GC0EACEEDT (N) T8V 2000 UL PR331/P LSI IN=2000A 3P F F NON-CANCELABLE, NON-RETURNABLE
Catalog Description: TMAX Breaker frame size T8, 2000A, 3 pole, long time, short time and instantaneous protection functions, very high 125kA @ 480V breaking capacity, 110-120 VAC/DC closing coil, 4 auxiliary contacts (supplied as standard for breakers with PR332 trip units), 100-130 VAC/DC spring charging motor, 110-120 shunt trip, 110-120 VAC/DC undervoltage - second shunt trip, bell alarm with remote reset, 110-130 VAC/DC, heary duty padlock, Underwriters Laboratories (sold in the US)
T8VBD3GC0EACEEDT Application
For power distribution applicationsT8VBD3GC0EACEEDT Item Features
- This construction characteristic allows for the CSA/UL listed field installation of internal accessories without exposure to energized parts
- Breakers from ABB ensure that the toggle indicates the precise position of the moving contacts, this guarantees safe and reliable signaling by the device
- Tmax molded case circuit breakers can be installed in panels and switchboards in either the horizontal or vertical planes while being fed from either end without any derating of their performance characteristics
- Compact size molded case circuit breaker
- All Tmax molded case circuit breakers are CSA/UL listed and IEC rated for global application and acceptance
- All versions of the Tmax family are suitable for reverse feed applications
- Very high interrupt rating class
- 2000 A frame
- 110 to 120 VAC/VDC shunt trip
- 110 to 120 VAC/VDC undervoltage release
- Bell alarm with remote reset 110 to 130 VAC/VDC
- 100 to 130 VAC/VDC spring charging motor
- 110 to 120 VAC/VDC closing coil
- 2000 A plug rating
- UL fixed 80% rated version
- 4 auxiliary contact
T8VBD3GC0EACEEDT Standards
UL 489|UL File No. E93565|CSA C22.2 No. 5|CSA File No. LR54280|IEC 60947-2SKU #2293637Part Number #T8VBD3GC0EACEEDTUNSPSC39121616UPC08057558255422
